Jacket package LED, the shape is rectangular with light emitting surface dimension 6.2mm x 3.7mm. This series jacket LED can be used on lighting indicator, status lights, on/off indicator and also backlight illumination. Victory has all color range from blue, green, yellow and red.

For multi color
# PDF Part No Emitted Color λd(nm) λp(nm) Lens Color Iv(mcd) Min. Iv(mcd) Typ. Angle (2θ ½) VF (Volt) @IF (mA)
1 VT R2D6.24 Blue 470 468 Blue 10 20 110 3.3 20
2 VT R3D6.26 True-green 525 518 Green 10 25 120 3.3 20
3 VT R5D6.24 Green 573 575 Green 10 15 120 2.0 20
4 VT R6D6.30 Yellow 589 591 Yellow 28 53 120 2.0 20
5 VT R7D6.30 Red 624 632 Red 28 55 120 2.0 20
